ASTRO APS

A versatile state-of-the-art star tracker

The ASTRO APS star tracker – a star sensor ready for all types of missions in LEO, MEO, HEO GEO orbit as well as deep space and human space.

Our ASTRO APS star sensor (star Tracker) is used by our customers in the space industry worldwide. From America (including Boeing, MAXAR, NASA) through Europe (including Airbus Defense and Space, OHB, ESA) to Asia (including JAXA), the ASTRO APS has established itself as a reliable and powerful star sensor.

Alphasat (2013), Orion (successful completed Artemis-1 mission in 2022, more to follow), Roman Space-Telescope (to be launched in 2025) and MSR-ERO (to be launched in 2026) are just a few mission, which rely on the ASTRO APS.

ASTRO APS is an autonomous star sensor with the most advanced radiation hard CMOS Active Pixel Sensor (APS) detector technology.

A single box design has been chosen with minimized dimensions, low mass and low power consumption while maximizing the ease of integration on the spacecraft. ASTRO APS shows high reliability and radiation hardness by careful selection of EEE Parts, reduced number of components and special software algorithms to cope with radiation events.

The technical key parameters of the ASTRO APS based star sensor are the low mass budget with approx. 2kg, the low power consumption with approx. 5W and the attitude quaternion accuracy of <1arcsec (1sigma). These data define a new level of compactness compared to CCD-based star sensors for the GEO telecom market (>18 years lifetime, <25 years radiation robustness for GEO missions).

The improvements in dimensions and performance were enabled due to the replacement of the CCD detector with the APS (Active Pixel Sensor) detector technology. The mass and envelope benefit is based on the very high functional integration of the APS detectors. The complete analogue read-out and sampling electronics are placed on the detector chip. This saves PCB area compared to CCD-based systems. The parts count for an APS based star sensor is reduced accordingly. Along with that, the unit costs are reduced and the system reliability is increased. The concept is modular and allows the use of either the STAR1000 or the HAS2 detector chip.
